Automatic Mini Best Selling PE Film Blowing Machine
Product Information This mini PE film blowing machine is an efficient and automatic device that has gained popularity in various industries. It is designed to blow LDPE and HDPE plastic films for creating different types of bags such as T-shirt bags, vest bags, shopping bags, and flat bags. The...
Description
Product Information
This mini PE film blowing machine is an efficient and automatic device that has gained popularity in various industries. It is designed to blow LDPE and HDPE plastic films for creating different types of bags such as T-shirt bags, vest bags, shopping bags, and flat bags. The equipment is widely used in food, clothing, and textile sectors.
The machine's primary function is to mold rubber and plastic film products, making it a crucial tool in the tape forming material industry. It enables the formulation development, performance research, and molding of film products, making it a versatile and essential device for the field. Overall, this machine is a reliable option for businesses looking to streamline their production process and improve efficiency.
Features
The automatic mini PE film blowing machine boasts a die head made of durable 45# steel that is plated with hard chromium. Its spiral mandrel structure ensures uniform extrusion of molten material, resulting in a finished product of high quality. The machine's screw and barrel are crafted from 38CrMoAI alloy, offering high hardness and superior corrosion resistance compared to standard nitriding screws, making it a durable choice over time. The machine has been designed to allow for rotational speed to be controlled by a frequency conversion motor during use, giving users the capability to adjust conveying speed to accommodate the creation of a variety of sheet products that conform to unique requirements.
There is an optional device available for the mini type film blowing machine. This device can be added to enhance the functionality and efficiency of the machine. By rearranging the original content, the following statement reflects the same information:
If you are looking to upgrade your mini type film blowing machine, there is an optional device that you should consider. This device is designed to improve the performance and productivity of the machine, making it more efficient and effective in its operations.
1. Auto Loader
2. Corona treatment
3. Automatic Air Supply Device
4. air shaft
Equipment Parameter:
Model | 45 model | 50 model |
Workable Materials | HDPE | |
Max.Film Width | 500mm | 600mm |
Max.Extrusion Output | HDPE:35kg/hr | |
Blown Film Thickness | HDPE:0.008-0.0.08mm | |
Extrusion Unit | ||
Hard-face Gear Case | 133 | 146 |
Screw Diameter | Φ45mm from Zhoushan China | Φ50mm from Zhoushan China |
Screw Material | 38 CRMOALA | |
Barrel's Material | ||
Screw L/D | 28:1 | 28:1 |
Main Motor Power | 7.5kw from Siemens | 11kw Siemens |
Frequency inverter | From Taiwan Delta | |
Cylinder Cooling | 250wx1 | 250wx2 |
Thermo Control (zone) | 2 | 2 |
Extrusion Die | ||
Die Size | HD:50mm | HD:60mm |
Screen Changer | Standard Manual | Standard Manual |
Thermo Control (Zone) | 2 | 2 |
Air Ring(mm) | Φ470 | Φ620 |
Cooling Blower(kw) | 1.1 | 1.5 |
Center Steady Stick | 1 pcs | |
Take-up Unit | ||
Traction Roller Width | φ138×550mm | φ138×650mm |
Embossing Roller Width | 450mm | 550mm |
Take up Motor(kw) | 0.75 | |
Take Up Speed | 10-80m/min | |
Winding Unit | ||
Rewinding Type | Surface Friction Winder ,Single Rewinder. | |
Rewinding shaft | manual shaft or Air expanding shaft | |
Roller Width | 550mm | 650mm |
Winding Motor | 10N.M | 1.1kw |
Rewinding Speed | 10-80m/min | |
Voltage | 380V,50HZ,3PHASE | |
Machine Dimension | 1450x2280x3200(mm) | 1450x2480x3200(mm) |
