Roll To Roll Automatic Rotogravure Printing Machine (ASY-600A)
Description The ASY-600A Roll To Roll Automatic Rotogravure Printing Machine is extremely versatile, capable of printing on a wide range of materials. One noteworthy aspect of this product is its use of non-toxic ink, which meets the highest standards for green and environmentally friendly...
Description

Description
The ASY-600A Roll To Roll Automatic Rotogravure Printing Machine is extremely versatile, capable of printing on a wide range of materials. One noteworthy aspect of this product is its use of non-toxic ink, which meets the highest standards for green and environmentally friendly printing practices. The ink layer produced by this machine is notably thick and uniformly colored, enabling it to effectively print a myriad of intricate patterns and reproduce the original effect flawlessly.
Unsurprisingly, this product finds extensive application in the beverage industry, traditional Chinese medicine preparation industry, soft packaging industry, and other related fields. By facilitating multi-color continuous printing and mass production, this machine significantly enhances printing efficiency and minimizes delivery times. As industry veterans, our team boasts extensive experience and expertise, making us the ideal point of contact for any inquiries or concerns you may have in this domain.
Features
Our product is equipped with an efficient color adjustment system that instantly and precisely corrects any color variations, resulting in a printed output that faithfully replicates the original document.
With a built-in drying mechanism, this printer is designed to expedite the ink drying process, effectively reducing the risk of smudging and transferring of ink onto unintended areas.
The printing machine is equipped with stainless steel heat dissipation fins to effectively prevent overheating caused by continuous printing.
The ASY-600A Roll To Roll Automatic Rotogravure Printing Machine boasts a durable construction built with high-quality materials that ensure steady operation and a long lifespan.
| Model | ASY-600A | ASY-800A | ASY-1000A |
| Printing colors | 8color | ||
| Max.printing width | 600 | 800mm | 1000 |
| Max.material width | 650 | 850mm | 1050 |
| Max.printing speed | 90-120m/min | 90-120m/min | 90-120m/min |
| Max.machine printing speed | 150m/min | 150m/min | 150m/min |
| Wind and unwind roller diameter | Φ800mm | Φ800mm | Φ800mm |
| Inner diameter | φ76mm | φ76mm | φ76mm |
| Printing cylinder diameter | φ120~φ320mm | φ120~φ320mm | φ120~φ320mm |
| Precision | ±0.15mm(wholeMachine) | ±0.15mm(wholeMachine) | ±0.15mm(wholeMachine) |
| Tension control | 0~25kg/FullWidth | 0~25kg/FullWidth | 0~25kg/FullWidth |
| Total power | 76kw | 84kw | 92kw |
| Machine weight | 19000kg | 20000kg | 21000kg |
| Machine dimension | 15200X2500X2500mm | 15200X2900X2500mm | 15200X3100X2500mm |
